FJL6920 High Output Transistor

Description

FJL6920 High Voltage Color Display Horizontal Deflection Output Transistor HOT.  TO-264 Package with BCE on this NPN triple diffussed planar silicon transistor.  This HOT can be used to replace most TO-247 and TO-264 High Output Transistors in most arcade monitors.  This FJL6920TU can replace the following 2SC5149, 2SC5589, 2SC4542, 2SC5150, 2SC5144, 2SC5411, 2SC3686, 2SC3688, 2SC4692, BU2532AL, BU2520AX, BU2520AW, BU4530AL, 2SC4769, 2SC5296, 2SC5297, 2SC5302, 2SC5584, 2SC5588, 2SC5143, 2SC5387, 2SC3997, 2SC5552, 2SC4288A, FJAF6808D, J6808D, FJL6820 and many others.  The FJL6920 is an Vceo 800V and Ic 20A and is a very reliable and robust HOT since it’s amperage rating is about twice as high as most monitors require.
